Superlux CMH8C Condenser Microphone

Specifications of Superlux CMH8C Condenser Microphone

  • Brand
  • SKU
  • Model
  • Mic Connectivity


0 People watching this product now!


Product details of Superlux CMH8C Condenser Microphone

  • Type: condenser microphone
  • Element: pressure gradient, FET preamplifier
  • Polar pattern: cardioid/omni/fig.8
  • Frequency response: 30~20000Hz
  • Sensitivity: -30.5/-35.4/-35.4dBV/Pa (28/17/17mV/Pa)
  • Rated impedance: 200 ohm
  • Minimum load impedance: 1000 ohm
  • Equivalent noise level: 14/18/18dB (A-weighted IEC/DIN651)
  • Max. SPL: 138/142/142dB (THD£ 0.5% 1000Hz)
  • Signal-to-noise ratio: 80/76/76dB
  • Dynamic range: 124dB
  • Power supply: 48V Phantom power (P48,IEC268-15/DIN 45596)
  • Current consumption: 4mA
  • Connector: 3 pins XLR gold-plated
  • Colour: Champagne-silver
  • Dimensions: Max.54mm(2.125″)x200mm(7.875″)
  • Weight: 567 g (20.1 oz)

SUPERLUX CMH8C – Platinum Series Large Diaphragm Studio Condenser Microphone Studio with 3 Pattern Dual Element Capsule – Omni, Cardioid or Figure of 8 – 10dB Pad and LF Roll-off Switch

The CM-H8C features a dual element 1″ diaphragm capsule. It can be switched for Omni, Cardioid or Figure “8” responses and has an external switch for the low-cut filter and a 10dB pad. It provides excellent performance in sensitivity, frequency response, dynamic range, noise and distortion. The CM-H8C is suitable for vocals, recording and high sound pressure levels.


  • Large 1″ diameter ultra-thin 3µm membrane gold-evaporated capsule.
  • Dual-element capsule permits the choice of three polar patterns selectable with an external switch.
  • Low noise transformer circuitry; flat and wide frequency response.
  • External low-frequency roll-off and 10dB pad attenuator switch.
